ECOPAN hot water radiant panel is hot water, hot steam or hot oil as a heat conduction medium, flow in the metal pipe of the radiant panel, use the radiant panel to generate infrared, directly through the air to heat the solid, people and other objects in heating area. The main features are:the special profile pressed on metal sheets, where housings are realized, to contain, wrapping them for the 2/3 of their surface, steel pipes having diameter 1/2”or 3/4”, electro-welded or without welding. The warmest part of the panel, is completely turned downwards and is wrapped by 70%of its surface by metal plate. Pipes, completely prominent under plates, create air cushions that reduce convective flows and increase radiance. The special care for dilations between pipe and sheet and the technical solutions that make installation easier.


  Energy-efficient
The system operates directionally in the heated zones where people are.The panels are so realized that the pipe,being the warmest part of the panel,is completely turned downwards and is wrapped by 70%of its surface by metal plate.Pipes,completely prominent under plates that reduce convective flows and increase radiance.This allows to obtain rapidly the required temperature,without long pre-heating times and consequent energy saving.

  Easy installation
The installation is particularly easy,quick and safe.The pipes of each modular element are connected by means of welding or pressfitting,which greatly guarantees the flexibility of installation.When pipe coupling is complete,a joint covering is inserted between the plates,which are easily inserted from below between the plates,so that installation times are reduced to the minimum level.Joint coverings have the same profile as main plates and laboratory tests confirm that the thermal output is exactly the same as the active plate of the panel where they are positioned.

  Immediate comfort
Comfort levels significantly improve with radiant heat panels.They distribute heat evenly across a room,eliminating cold spots and creating a cozy atmosphere.This method of warmth can feel more natural and pleasant than forced-air systems.Indoor air quality also benefits,as radiant heating doesn’t circulate dust.Workers can enjoy a warm environment without the uncomfortable dry air often associated with traditional heating methods.

  Cost saving
Radiant panel systems provide significant savings in construction costs due to their efficient use of space. There is very little involved with the maintenance of a ceiling.Once correctly installed,the radiant panels require little or no further maintenance as they have no moving parts,and are kept up and out of the way, so that the maintenance costs will be greatly reduced..This makes radiant panels particularly useful in high traffic areas such as busy airport walkways or school gymnasiums.

ECOPAN radiant panels are composed of 4 and/or 6 metres modules and different lengths are therefore obtained by connecting the pipes of each modular element by means of welding or pressfitting.The bracket of the suspension board is welded to the radiant panel,one per meter,which greatly guarantees the flexibility of installation.Meanwhile,a welding or pressfitting point is present in the middle of each sheet,therefore dilations on both sides are less than 1 mm.This grants that no deformation of the panel comes out during time.

When pipe coupling is complete,a joint covering is inserted between the plates,to cover the connection area.Joint coverings have the same profile as main plates and laboratory tests confirm that the thermal output is exactly the same as the active plate of the panel where they are positioned.Joint coverings are easily inserted from below between the plates and fastened with clips,so that installation times are reduced to the minimum level.



ECOPAN radiant panels are widely used to heat big volumes like industrial halls and warehouses, train and streetcar service workshops, airport hangars, gymnasiums and sport halls,as well as shopping and cultural structures like car dealers, shopping malls, concert halls, meeting rooms and many others.
